Historic Beer Birthday: Emil Christian Hansen

May 8, 2021 By Jay Brooks Leave a Comment

Today is the birthday of Emil Christian Hansen (May 8, 1842-August 27, 1909). Hansen was a “Danish botanist who revolutionized beer-making through development of new ways to culture yeast. Born poor in Ribe, Denmark, he financed his education by writing novels. Though he never reached an M.Sc., in 1876, he received a gold medal for an essay on fungi, entitled “De danske Gjødningssvampe.” In 1879, he became superintendent of the Carlsberg breweries. In 1883, he successfully developed a cultivated yeast that revolutionized beer-making around the world, because Hansen by refusing to patent his method made it freely available to other brewers. He also proved there are different species of yeast. Hansen separated two species: Saccharomyces cerevisiae, an over-yeast (floating on the surface of the fermenting beer) and Saccharomyces carlsbergensis, an under-yeast (laying on the bottom of the liquid).

Here’s his entry from Encyclopedia Britannica:

Danish botanist who revolutionized the brewing industry by his discovery of a new method of cultivating pure strains of yeast.

Hansen, who began his working life as a journeyman house painter, received a Ph.D. in 1877 from the University of Copenhagen. Two years later he was appointed head of the physiology department at the Carlsberg Laboratory in Copenhagen, where he remained until his death. His research was concerned mainly with yeasts that convert carbohydrates to alcohol, and in 1888 he published an article that described his method for obtaining pure cultures of yeast. The yeast grown from these single strains was widely adopted in the bottom-fermentation brewing industries. Further investigations led him to the discovery of a number of species of yeast. He defined the characters of the different species and devised a system of classification. After further study he devised additional methods for the culture and isolation of certain species.

Emil Hansen as a young man.

This is how Carlsberg describes Hansen’s breakthrough in 1883:

The Carlsberg Laboratory made its first major scientific breakthrough when Dr. Emil Chr. Hansen developed a method for propagating pure yeast.

Fluctuations in the beer quality were not unknown at the time, but had until then been solved by thorough cleaning of all installations after suspension of production. If a brew failed, there was no use in pasteurising it; it had to be destroyed.

In 1883, the Old Carlsberg beer got infected with the beer disease and all efforts were made to find a solution to the problem.

Dr. Emil Chr. Hansen who joined the Carlsberg Laboratory in 1878 was examining the beer, and he found that it contained wild yeast. Through his studies and analyses, he discovered that only a few types of yeast (the pure yeast) are suitable for brewing, and he developed a technique to separate the pure yeast from the wild yeast cells. The problem had been solved, and the new Carlsberg yeast – Saccharomyces Carlsbergensis – was applied in the brewing process.

The propagating method revolutionised the brewing industry. Rather than to patent the process, Carlsberg published it with a detailed explanation so that anyone could build propagation equipment and use the method. Samples of the yeast – Saccharomyces Carlsbergensis – were sent to breweries around the world by request and young brewers came to Carlsberg to learn the skills.

This is the entry from Wikipedia on the history of Saccharomyces Carlsbergensis:

So-called bottom fermenting strains of brewing yeast were described as early as the 14th century in Nuremberg and have remained an indispensable part of both Franconian and Bavarian brewing culture in southern Germany through modern times. During the explosion of scientific mycological studies in the 19th century, the yeast responsible for producing these so-called “bottom fermentations” was finally given a taxonomical classification, Saccharomyces pastorianus, by the German Max Reess in 1870.

In 1883 the Dane Emil Hansen published the findings of his research at the Carlsberg brewery in Copenhagen and described the isolation of a favourable pure yeast culture that he labeled “Unterhefe Nr. I” (bottom-fermenting yeast no. 1), a culture that he identified as identical to the sample originally donated to Carlsberg in 1845 by the Spaten Brewery of Munich. This yeast soon went into industrial production in Copenhagen in 1884 as Carlberg yeast no. 1.

In 1904 Hansen published an important body of work where he reclassified the separate yeasts he worked with in terms of species, rather than as races or strains of the same species as he had previously done. Here Hansen classified a separate species of yeast isolated from the Carlsberg brewery as S. pastorianus, a name derived from and attributed to Reess 1870. This strain was admitted to the Centraalbureau voor Schimmelcultures (CBS) in 1935 as strain CBS 1538, Saccharomyces pastorianus Reess ex Hansen 1904. In a further publication in 1908, Hansen reclassified the original “Unterhefe Nr. I” as the new species Saccharomyces carlsbergensis and another yeast “Unterhefe Nr. II” as the new species Saccharomyces monacensis. The taxonomy was attributed to Hansen 1908 and the yeasts entered into the Centraalbureau voor Schimmelcultures in 1947 as CBS 1513 and CBS 1503 respectively.

Since the early 1900s, bottom-fermenting strains of brewery yeast have been typically classified as S. carlbergensis in scientific literature, and the earlier valid name assigned to a bottom-fermenting yeast by Reess in 1870 was rejected without merit. This situation was rectified using DNA-DNA reallocation techniques in 1985 when Vaughan-Martini & Kurtzman returned the species name to S. pastorianus under the type strain CBS 1538 and relegated the two former species assigned by Hansen in 1908, S. carlsbergensis CBS 1513 and S. monacensis CBS 1503, to the status of synonyms. These experiments also clearly revealed the hybrid nature of the lager brewing yeast species for the first time, even though one of the parental species was incorrectly classified in retrospect. Nonetheless, over the last decades of the 20th century, debate continued in scientific literature regarding the correct taxon, with authors using both names interchangeably to describe lager yeast.

Although most accounts mention that he wrote novels to put himself through school, one has a slightly different take, though I’m not sure how true it is. “Emil earned his bread and butter as a painter but he yearned for another life and left Ribe so he could study. He graduated from High School relatively late – he was 29 years old.”

Emil Christian Hansen, taken in 1908, a year before his death.

Historic Beer Birthday: Anton Schwarz

February 2, 2021 By Jay Brooks Leave a Comment

Today is the birthday of Anton Schwarz (February 2, 1839-September 24, 1895). In addition to having studied law, he also became a chemist and worked for several breweries in Budapest, before moving to the U.S. in 1868. Moving to New York, he got a job working for the magazine/journal American Brewer, which at the time was more like the People magazine of the brewing industry. He was quickly promoted to editor, eventually buying the publication. He turned it into a serious scientific journal, writing many of the articles himself, but is credited with helping the entire industry improve its standards and processes.

Here’s his entry from the Jewish Encyclopedia, published in 1906.

Austrian chemist; born at Polna, Bohemia, Feb. 2, 1839; died at New York city Sept. 24, 1895. He was educated at the University of Vienna, where he studied law for two years, and at the Polytechnicum, Prague, where he studied chemistry. Graduating in 1861, he went to Budapest, and was there employed at several breweries. In 1868 he emigrated to the United States and settled in New York city. The following year he was employed on “Der Amerikanische Bierbrauer” (“The American Brewer”) and soon afterward became its editor. A few years later he bought the publication, remaining its editor until his death. He did much to improve the processes of brewing in the United States, and in 1880 founded in New York city the Brewers’ Academy of the United States.

Schwarz’s eldest son, Max Schwarz (b. in Budapest July 29, 1863; d. in New York city Feb. 7, 1901), succeeded him as editor of “The American Brewer” and principal of the Brewers’ Academy. He studied at the universities of Erlangen and Breslau and at the Polytechnic High School at Dresden. In 1880 he followed his father to the United States and became associated with him in many of his undertakings.

Both as editor and as principal of the academy he was very successful. Many of the essays in “The American Brewer,” especially those on chemistry, were written by him. He was a great advocate of the “pure beer” question in America.

When the United States Brewers’ Academy celebrated its 25th anniversary, in 1913, there was a ball where several alumni gave speeches and toasts, mentioning Schwarz’ contributions, including this from Gallus Thomann from Germany:

He also co-wrote the Theory and Practice of the Preparation of Malt and the Fabrication of Beer

Beer Advocate also has a nice story of Schwarz, entitled the O.G. Beer Geek.

Historic Beer Birthday: James Watt

January 19, 2021 By Jay Brooks Leave a Comment

Today is the birthday of James Watt, not the BrewDog co-founder, but the “Scottish inventor, mechanical engineer, and chemist who improved on Thomas Newcomen’s 1712 Newcomen steam engine with his Watt steam engine in 1781, which was fundamental to the changes brought by the Industrial Revolution in both his native Great Britain and the rest of the world.

While working as an instrument maker at the University of Glasgow, Watt became interested in the technology of steam engines. He realised that contemporary engine designs wasted a great deal of energy by repeatedly cooling and reheating the cylinder. Watt introduced a design enhancement, the separate condenser, which avoided this waste of energy and radically improved the power, efficiency, and cost-effectiveness of steam engines. Eventually he adapted his engine to produce rotary motion, greatly broadening its use beyond pumping water.

Watt attempted to commercialise his invention, but experienced great financial difficulties until he entered a partnership with Matthew Boulton in 1775. The new firm of Boulton and Watt was eventually highly successful and Watt became a wealthy man. In his retirement, Watt continued to develop new inventions though none was as significant as his steam engine work. He died in 1819 aged 83.

He developed the concept of horsepower, and the SI unit of power, the watt, was named after him.”

A portrait of James Watt, by Carl Frederik von Breda, completed in 1792.

Of course, from our perspective his most important contribution was to the industrial revolution, and specifically the improvement of brewery efficiency. While Watt did not invent the steam engine, his improvements made it practical, especially in breweries.

The Watt Steam Engine

The Watt steam engine (alternatively known as the Boulton and Watt steam engine) was the first type of steam engine to make use of a separate condenser. It was a vacuum or “atmospheric” engine using steam at a pressure just above atmospheric to create a partial vacuum beneath the piston. The difference between atmospheric pressure above the piston and the partial vacuum below drove the piston down the cylinder. James Watt avoided the use of high pressure steam because of safety concerns. Watt’s design became synonymous with steam engines, due in no small part to his business partner, Matthew Boulton.

The Watt steam engine, developed sporadically from 1763 to 1775, was an improvement on the design of the Newcomen engine and was a key point in the Industrial Revolution.

Watt’s two most important improvements were the separate condenser and rotary motion. The separate condenser, located external to the cylinder, condensed steam without cooling the piston and cylinder walls as did the internal spray in Newcomen’s engine. Watt’s engine’s efficiency was more than double that of the Newcomen engine. Rotary motion was more suitable for industrial power than the oscillating beam of Newcomen’s engine.

Watt’s most famous steam engine was the one installed at the Whitbread Brewery in 1785, which was known as the Whitbread Engine. Today it’s located in the Powerhouse Museum in Sydney, Australia.

The Whitbread Engine

The Whitbread Engine preserved in the Powerhouse Museum in Sydney, Australia, built in 1785, is one of the first rotative steam engines ever built, and is the oldest surviving. A rotative engine is a type of beam engine where the reciprocating motion of the beam is converted to rotary motion, producing a continuous power source suitable for driving machinery.

This engine was designed by the mechanical engineer James Watt, manufactured for the firm Boulton and Watt and originally installed in the Whitbread brewery in London, England. On decommissioning in 1887 it was sent to Australia’s Powerhouse Museum (then known as the Technological, Industrial and Sanitary Museum) and has since been restored to full working order.

Installation of the Watt Steam Engine at Whitbread.

History of the Whitbread Engine

The engine was ordered by Samuel Whitbread in 1784 to replace a horse wheel at the Chiswell Street premises of his London brewery. It was installed in 1785, the second steam engine to be installed in a brewery, and enabled Whitbread to become the largest brewer in Britain. The horse wheel was retained for many years, serving as a backup in case the steam engine broke down. The drive gear of the engine, still evident today, was connected to a series of wooden line shafts which drove machinery within the brewery. Connected machinery included rollers to crush malt; an Archimedes’ screw, that lifted the crushed malt into a hopper; a hoist, for lifting items into the building; a three-piston pump, for pumping beer; and a stirrer within a vat. There was also a reciprocating pump connected to the engine’s beam, used to pump water from a well to a tank on the roof of the brewery.

In a marketing coup for both the brewer and the engine’s manufacturer, King George III and Queen Charlotte visited the brewery on 24 May 1787. The engine remained in service for 102 years, until 1887.

The engine made its way to the Powerhouse Museum (then known as the Technological, Industrial and Sanitary Museum) through Archibald Liversidge, an English-born chemist, scientist and academic at the University of Sydney, who was a trustee of the museum. Liversidge was in London in 1887, at the time of the engine’s decommissioning, and when he heard that the engine was to be scrapped he asked whether it could be donated to the museum. Whitbread & Co agreed on condition that the engine be set up and used for educational purposes.

Subsequently, the engine was dismantled and shipped to Sydney on the sailing ship Patriarch. For shipping purposes, the large flywheel was divided into two halves. While the flywheel’s rim could be unbolted, the hub with attached spokes had to be drilled through and rejoined after shipping. A shortage of funds meant the engine was kept in storage for several years. Eventually the engine was erected in its own engine house, behind the main building at the museum’s old Harris Street premises. During the 1920s or 1930s, an electric motor was added so that people could see the engine in motion. During the 1980s the Technology Restoration Society was formed in order to raise funds for the engine’s restoration. Restoration took place at the Museum’s Castle Hill site. During the restoration, some parts – including the piston – were replaced to preserve the original parts. The engine, restored to steaming condition, was installed in the new Powerhouse Museum in 1988. Today the engine is sometimes operated as part of the Museum’s Steam Revolution exhibition, steam being provided by the Museum’s central boiler.

Technical specifications

The engine has a 0.64 metres (25 in) diameter piston with a 1.8 metres (6 ft) long stroke, driven by a mean effective pressure of 70 kilopascals (10 psi). Its top speed is 20 revolutions per minute (rpm) of the flywheel. In the engine’s youth, it had a maximum power output of approximately 26 kilowatts (35 hp).[It underwent a series of alterations in 1795, converting it from single-acting to double-acting; it was alleged at the time that this conversion improved its power to 52 kilowatts (70 hp), but the Powerhouse Museum claims this is false. A centrifugal governor, which moderates the level of steam provided if the engine begins to overload was added some years after this, and beam and main driving rod, both originally of wood, were replaced in sand-cast iron.

Apart from its age, the engine is notable in that it embodies the four innovations which made Boulton & Watt’s engines a significant driver of the Industrial Revolution. The first is a separate condenser, which increases the efficiency of the engine by allowing the main cylinder to remain hot at all times. The second is the parallel motion, which converts the up-and-down motion of the piston into the arcing motion of the beam, whilst maintaining a rigid connection. The rigid connection allowed the engine to be double-acting, meaning the piston could push as well as pull the beam. Third is the centrifugal governor, used to automatically regulate the speed of the engine. Finally the sun and planet gear convert the reciprocating motion of the beam into a rotating motion, which can be used to drive rotating machinery.

There’s also another Boulton & Watt engine at the National Museum of Scotland. It “was built in 1786 to pump water for the Barclay & Perkins Brewery in Southwark, London. Made double-acting in 1796, it was then capable of grinding barley and pumping water. At that time, no one else could supply a steam engine that performed both these actions at once. With some minor modifications, it remained in service at the brewery until 1884.”

And this is more from the National Museum of Scotland:

James Watt (1736-1819) was a prolific inventor, surveyor, instrument maker and engineer. His engines dramatically increased the power that could be generated through steam.

By entering into partnership with the Birmingham magnate Matthew Boulton in 1774, James Watt was able to channel the vast resource of Boulton’s Soho Foundry. Their partnership was so successful that the Boulton & Watt firm supplied engines and expertise to countries as far a field as Russia and Greece.

After pumping water and grinding barley for almost eighty-seven years, the engine came out of service in 1883.

You can see a diagram of the engine in action here:

Watt’s Steam Engine

Inside the Engine

Lighting the Fire

Running the Engine

If you want to read more in-depth about Watt’s development of the steam engine, Chapter III of “The Development of the Modern Steam-Engine: James Watt and His Contemporaries” is online, and there’s also various links at Watt’s page at the Scottish Engineering Hall of Fame.

Historic Beer Birthday: Gerardus Johannes Mulder

December 27, 2020 By Jay Brooks Leave a Comment

Today is the birthday of Gerardus Johannes Mulder (December 26, 1802–April 18, 1880). He “was a Dutch organic and analytical chemist,” who wrote several technical chemical publications analyzing various substances, including one entitled “The Chemistry of Beer,” in 1856 or 57 (sources vary).

“He became a professor of chemistry at Rotterdam and later at Utrecht. While at the Utrecht University, Mulder described the chemical composition of protein. He claimed that albuminous substances are made up of a common radical, protein, and that protein had the same empirical formula except for some variation in amounts of sulfur and phosphorus, long before the polymer nature of proteins was recognized after work by Staudinger and Carrothers.

He was the first to use this name, protein, coined by Jöns Jacob Berzelius in a publication, his 1838 paper ‘On the composition of some animal substances’ (originally in French but translated in 1839 to German). In the same publication he also proposed that animals draw most of their protein from plants.”

Here’s a biography of Mulder from Encyclopedia.com:

Mulder studied medicine at the University of Utrecht (1819–1825), from which he graduated with a dissertation on the action of alkaloids of opium, De opio ejusque principiis, actione inter se comparatis (1825). He practiced medicine in Amsterdam and then in Rotterdam, where he also lectured at the Bataafsch Genootschap der Proefondervindelijke Wijsbegeerte and taught botany to student apothecaries. At the foundation of a medical school at Rotterdam (1828), Mulder became lecturer in botany, chemistry, mathematics, and pharmacy. His attention was directed primarily to the practical training of his students. In 1840 Mulder succeeded N. C. de Fremery as professor of chemistry at the University of Utrecht. He applied for his retirement in 1868 and spent the rest of his life in Bennekom. Besides publishing on scientific subjects, Mulder took an active part in education, politics and public health. The works of Faraday and Berzelius exerted a great influence on him; his Leerboek voor Scheikundige werktuigkunde (1832–1835) was written in the spirit of Faraday’s Chemical Manipulation. Mulder edited a Dutch translation by three of his students of Berzelius’ textbook of chemistry as Leerboek der Scheikunde (6 vols., 1834–1845). His difficult character caused problems with some of his pupils and with other chemists.

From 1826 to 1865 Mulder edited five Dutch chemical journals (see bibliography), in which most of his work was published. He worked in physics and in both general and physical chemistry, the latter in combination with medicine, physiology, agriculture, and technology. Most of his work had a polemic character. His most important contributions are in the field of physiological chemistry and soil chemistry, in which he published two extensive works that attracted much attention in translation despite their many mistakes and erroneous speculations.

Studies on proteins led Mulder to his protein theory (1838): he supposed that all albuminous substances consist of a radical compound (protein) of carbon, hydrogen, nitrogen, and oxygen, in combination with varying amounts of sulfur and phosphorus. The differences among proteins resulted from multiplication of the protein units in conjunction with the two other elements. Thus, casein was formulated as

10 protein units + S,

And serum albumin as

10 protein units + SP2.

In 1843 Mulder published the first volume of a treatise on physiological chemistry, which was translated into English as The Chemistry of Vegetable and Animal Physiology (1845–1849). At first both Liebig and Berzelius accepted Mulder’s analysis of proteins; but Liebig soon opposed the theory vigorously, and a deep conflict with Mulder ensued. In 1839–1840 Mulder investigated humic and ulmic acids and humus substances and determined the amounts of geic acid (acidum geïcum), apocrenic acid (acidum apocrenicum or Quellsatzsäure), crenic acid (acidum crenicum or Quellsäure), and humic acids in fertile soils (1844). The structure of these various brown or black substances is unknown. They are a group of aromatic acids of high molecular weight, which can be extracted from peat, turf, and decaying vegetable matter in the soil. The difference between these acids is the oxygen content. In the decay of vegetable matter ulmic acid is formed. According to Mulder, this has the formula C20H14O6(in modern equivalents). In contact with air and water more oxygen is absorbed, which results in the successive formation of humic acid (C20H12O6, geic acid (C20H12O7), apocrenic acid C24H12O12, and crenic acid (C12H12O8).

His studies on agricultural chemistry led to the treatise De scheikunde der bouwbare aarde (1860). Mulder confirmed Berzelius’ suggestion that theine and caffeine are identical (1838) and was the first to analyze phytol correctly in his researches on chlorophyll. Among his other works are technical chemical publications on indigo (1833), wine (1855), and beer (1856), detailed research on the assaying method for analyzing silver in relation to the volumetric silver determination of Gay-Lussac (1857), and a study on drying oils (1865).

While I can’t find the book itself, Julius E. Thausing mentions it in his “Theory and Practice of the Preparation of Malt and the Fabrication of Beer,”published in 1882.

Historic Beer Birthday: Louis Pasteur

December 27, 2020 By Jay Brooks Leave a Comment

Today is the birthday of Louis Pasteur (December 27, 1822–September 28, 1895). He “was a French chemist and microbiologist renowned for his discoveries of the principles of vaccination, microbial fermentation and pasteurization. He is remembered for his remarkable breakthroughs in the causes and preventions of diseases, and his discoveries have saved countless lives ever since. He reduced mortality from puerperal fever, and created the first vaccines for rabies and anthrax. His medical discoveries provided direct support for the germ theory of disease and its application in clinical medicine. He is best known to the general public for his invention of the technique of treating milk and wine to stop bacterial contamination, a process now called pasteurization. He is regarded as one of the three main founders of bacteriology, together with Ferdinand Cohn and Robert Koch, and is popularly known as the ‘father of microbiology.'”

But, of course, for the brewing industry, he’s best remembered for his “Studies on Fermentation,” which he published in 1876.

In 1876, Louis Pasteur published his ground-breaking volume, Études sur la Bière, soon translated into English as Studies On Fermentation. The book changed the course of brewing during the late 19th and early 20th centuries, representing a huge leap forward in the scientific understanding of the processes involved in beermaking. Brewers around the globe put Pasteur’s findings to work in their breweries, and thus plunged the industry headlong into the modern era.

In tribute to Pasteur’s tremendous contributions to brewing science, BeerBooks.com has reprinted Studies On Fermentation exactly as it appeared when first released in English, complete with all of Pasteur’s illustrations. An original 1879 edition was digitally scanned, professionally enhanced and reproduced in a hard cover format.

In his preface, Pasteur modestly wrote, “I need not hazard any prediction concerning the advantages likely to accrue to the brewing industry from the adoption of such a process of brewing as my study of the subject has enabled me to devise, and from an application of the novel facts upon which this process is founded. Time is the best appraiser of scientific work, and I am not unaware that an industrial discovery rarely produces all its fruits in the hands of its first inventor.”

But, of course, the brewing industry recognized almost immediately the impact that Pasteur’s work would have on the art and science of beermaking. Frank Faulkner, the British brewing scholar who performed the English translation, wrote, “Seeing the vast importance of Pasteur’s work from a practical point of view, after writing a review of it for the Brewers’ Journal, I determined to procure, at any rate for the use of my own pupils, a literal translation, illustrated by photo-lithographic copies of the original plates…It was on the completion of this translation that my views and desires expanded. The more I studied the work, the more I was convinced of its immense value to the brewer as affording him an intelligent knowledge of the processes and materials with which he deals…I determined accordingly to publish the work if I could secure the consent of its distinguished author…The debt which we English brewers owe to M[r]. Pasteur can hardly be over-estimated.”

While I’m sure there are probably many more, he had patents I highlighted last year, Patent No. 135245A: Improvement in Brewing Beer and Ale from 1873, and Patent No. 141072A: Manufacture of Beer and Yeast, in the same year.

A portrait of Louis Pasteur painted by Swedish-speaking Finnish artist Albert Edelfelt, in 1886.

Fermentation and germ theory of diseases

Pasteur demonstrated that fermentation is caused by the growth of micro-organisms, and the emergent growth of bacteria in nutrient broths is due not to spontaneous generation, but rather to biogenesis (Omne vivum ex vivo “all life from life”). He was motivated to investigate the matter while working at Lille. In 1856 a local wine manufacturer, M. Bigot, the father of his student, sought for his advice on the problems of making beetroot alcohol and souring after long storage. In 1857 he developed his ideas stating that: “I intend to establish that, just as there is an alcoholic ferment, the yeast of beer, which is found everywhere that sugar is decomposed into alcohol and carbonic acid, so also there is a particular ferment, a lactic yeast, always present when sugar becomes lactic acid.” According to his son-in-law, Pasteur presented his experiment on sour milk titled “Latate Fermentation” in August 1857 before the Société des Sciences de Lille. (But according to a memoire subsequently published, it was dated November 30, 1857). It was published in full form in 1858. He demonstrated that yeast was responsible for fermentation to produce alcohol from sugar, and that air (oxygen) was not required. He also demonstrated that fermentation could also produce lactic acid (due to bacterial contamination), which makes wines sour. This is regarded as the foundation of Pasteur’s fermentation experiment and disprove of spontaneous generation of life.

Pasteur’s research also showed that the growth of micro-organisms was responsible for spoiling beverages, such as beer, wine and milk. With this established, he invented a process in which liquids such as milk were heated to a temperature between 60 and 100 °C. This killed most bacteria and moulds already present within them. Pasteur and Claude Bernard completed the first test on April 20, 1862. Pasteur patented the process, to fight the “diseases” of wine, in 1865. The method became known as pasteurization, and was soon applied to beer and milk.

Beverage contamination led Pasteur to the idea that micro-organisms infecting animals and humans cause disease. He proposed preventing the entry of micro-organisms into the human body, leading Joseph Lister to develop antiseptic methods in surgery. Lister’s work in turn inspired Joseph Lawrence to develop his own alcohol-based antiseptic, which he named in tribute Listerine.

This is an ad is for Whitbread, from 1937, showing an illustration of Louis Pasteur working on his fermentation studies in a laboratory at Whitbread Brewing in 1871, nine years after he completed his first test of pasteurization, which took place April 20, 1862.

On his Wikipedia page, under the heading “Controversies, there’s this paragraph about his research into fermentation:

When Pasteur published his theory and experiments on fermentation in 1858, it was not new to science, neither the idea nor the experiment. In 1840 a German chemist Justus von Liebig had noted that yeast could induce fermentation in water. However, he did not know that yeasts were organisms. In 1856 another German, Friedrich Wilhelm Lüdersdorff, reported that yeasts were microorganisms that convert sugar into alcohol. In 1855, Antoine Béchamp, Professor of Chemistry at the University of Montpellier, showed that sugar was converted to sucrose and fructose in a closed bottle containing water and when he added calcium or zinc chloride to it, no reaction occurred. He also noticed moulds developing in the solution, but could not fathom the significance of it. He concluded that water was the factor for fermentation. He changed his conclusion in 1858 that water was not the main factor, in fact, fermentation was directly related to the growth of moulds, and moulds required air for growth. He regarded himself as the first to show the role of microorganisms in fermentation. Pasteur started his experiments only in 1857 and published his findings in 1858 (April issue of Comptes Rendus Chimie, Béchamp’s paper appeared in January issue), which, as Béchamp noted, did not bring any novel idea or experiments that earlier works had not shown. On the other hand, Béchamp was probably aware of Pasteur’s 1857 preliminary works. With both scientists claiming priority on the discovery, a bitter and protracted dispute lasted throughout their lives. Their rivalry extended to ideas on microbiology, pathogenesis, and germ theory. Particularly on the spontaneous generation because Pasteur in his 1858 paper explicitly stated that the lactic acid bacteria (he named them “lactic yeasts”), which caused wine souring, “takes birth spontaneously, as easily as beer yeast every time that the conditions are favourable.” This statement directly implied that Pasteur did believe in spontaneous generation. He condemned the ideas of Pasteur as “‘the greatest scientific silliness of the age”. However, Béchamp was on the losing side, as the BMJ obituary remarked: His name was associated with bygone controversies as to priority which it would be unprofitable to recall. Pasteur and Béchamp believed that fermentation was exclusively cellular activity, that is, it was only due to living cells. But later extraction of enzymes such as invertase by Marcellin Berthelot in 1860 showed that it was simply an enzymatic reaction.

Pasteur’s ground-breaking “Studies on Fermentation” is in the public domain, of course, so you can read the entire work, or just browse through it, at the Internet Archive.

In 1951, the United States Brewers Foundation featured Louis Pasteur in an ad, which was part of a series that used a Q&A format aimed at highlighting different positive aspects of beer and the brewing industry.

Historic Beer Birthday: Michael Edward Ash

December 17, 2020 By Jay Brooks Leave a Comment

Today is the birthday of Michael Edward Ash (December 17, 1927–April 30, 2016). He “was a British mathematician and brewer. Ash led a team that invented a nitrogenated dispense system for Guinness stout, which evolved to become the beer now sold globally as Draught Guinness. As the manager in charge of the Easy Serve project, Ash is credited as the inventor of nitrogenated beer (sometimes known as “nitro beer” colloquially).”

Michael Ash in the 1950s.

“Following graduation from Cambridge, Ash lectured in mathematics at The Bedford College for women for three years before joining Guinness & Co. at their London Brewery in Park Royal in January 1951.

After training as a brewer by 1954 Ash also had experience of running two departments (Brewing and Forwarding) and in 1955 he was given his own department the ‘Sample Room’, which had facilities for experimentation. The ‘Draught problem’ was given to Ash as part of his briefing from the managing Director, Hugh Beaver. At the time, Guinness used a convoluted draught system in which highly conditioned beer was blended with aged, nearly still beer. It was a slow, arduous process that limited the ability of draught dispense to reach a more global market.

Guinness had for years been looking for a system in which a barman with no special training could pour a glass of draught in a matter of seconds to settle quickly with a head (3/8″ in a normal ½ pint glass).

Ash realized the solution lay in the use of a blend of nitrogen and carbon dioxide (beer typically just uses the latter), but it took years to figure out a mechanism to dispense nitrogenated beer. Inside Guinness, Ash’s quest was regarded as quixotic, and other brewers chided it as “daft Guinness” and the “Ash Can.” Eventually, working with a keg designer, Ash hit on a revolutionary, self-contained two-part keg, with one chamber full of beer and the other full of mixed gas under pressure, and the introduction of nitrogen.[5] Nitrogen is less soluble than carbon dioxide, which allows the beer to be put under high pressure without making it fizzy. The high pressure of dissolved gas is required to enable very small bubbles to be formed by forcing the draught beer through fine holes in a plate in the tap, which causes the characteristic ‘surge’.

Ultimately called the “easy serve system,” it began to replace the old “high and low” taps used in Ireland and spread to Great Britain and beyond beginning in the 1960s. The invention, which made for a smoother, less characterful beer, was not without controversy, and for years a minority of Irish drinkers complained about the change. Eventually, nitrogrenated stout became a standard, not just at Guinness but among all Irish makers of stout.

Ash left the brewing side of Guinness in 1962 to become managing director of Crooks Laboratories in Park Royal (owned by Guinness). Crooks moved to Basingstoke in 1965. At Crooks Ash was responsible for acquiring the licence for the anti-depressant Prothiaden (Dosulepin) in 1967. From 1970 onwards Ash followed various interests including business education and was a founding governor of Templeton College Oxford.”

Ash with Pete Brown.

Pete Brown, who’d met Ash recently, wrote his obituary for the Morning Advertiser after he passed away in April of this year at 88 years old, entitled The man who created the nitro stout.

A photograph of Ash taken by Jeff Alworth during his visit to Guinness in early 2016.

Similarly, Jeff Alworth wrote a piece for All About Beer Magazine, The Man Who Invented Nitro the month after he passed away.

Alworth’s article online includes an audio clip of Michael Ash describing the process he used to create Draught Guinness using nitrogen.

And this biography of Ash was prepared by Guinness’ marketing department:

Michael read mathematics at Trinity College, Cambridge and was awarded a triple first in his studies – top scholar that year in Cambridge. Between 1948 – 1950, Michael was allowed to reduce his national service conscription by teaching Maths at a University (other than Oxbridge). He taught at Bedford College. Up to the end of World War Two, the Guinness Company had a policy of recruiting only first class honours science graduates from Oxford or Cambridge. Michael was the first non-brewer to be recruited into Guinness.

It was in this role, he led a team of over 20, and their primary role was to seek to improve the shelf life of bottled Guinness. However, Michael felt that the real prize was in developing a proper system for Draught Guinness and began dedicating his time to the ‘Draught Problem’.

The rise of lagers available on draught, especially in the UK in the 1940s and 1950s, was encroaching on traditional Guinness sales, and Michael felt that there was a great opportunity for Guinness, should the stout be available in Draught format. However, the essential problem was with the gas. Carbon dioxide was used to pressurise kegs of bitter and lager, and it was easy and effective for everyone concerned. Guinness, though was too lively to be draughted with carbon dioxide alone.

Of the 20 plus men on his Sample Room team, he could only afford to assign 2 people to work part-time with him on ‘Daft Guinness’ as it became known with the Park Royal Brewery. Michael talks about working weekends and late nights over a long period of time to eventually come up with a nitrogen gas solution.

He worked hand in hand with Eric Lewis, of Alumasc, who supplied Michael with prototype after protoype of metal kegs with different experimental gas chambers. The fact that nitrogen is an inert gas meant that they bubbles lasted longer and were smaller. The right amount of nitrogen, created the ‘surge’ and allowed for a controlled, creamy head that lasts for the whole pint.

The eventual solution was a ‘mixed gas dispense’ system. Known initially as ‘The Ash Can’, The Easy Serve Cask was a self-contained, two-part keg, with one chamber full of beer and the other full of mixed gas under pressure.

Having seen the possibilities, [the company] was in a hurry to get Draught Guinness out into the market place, and he demanded that it should be launched in 1959 – the year of the Guinness bicentenary. At a board meeting of 9 December 1959 – Viscount Elveden (later 3rd Lord Iveagh) reported that about half the draught Guinness outlets had now been changed to the Easy Serve system, and the changeover of the remainder should take place by mid-January 1960.

Here’s a short video that Guinness made about Michael Ash:

Historic Beer Birthday: Theodor Schwann

December 7, 2020 By Jay Brooks Leave a Comment

Today is the birthday of Theodor Schwann (December 7, 1810–January 11, 1882). He “was a German physiologist. His many contributions to biology include the development of cell theory, the discovery of Schwann cells in the peripheral nervous system, the discovery and study of pepsin, the discovery of the organic nature of yeast, and the invention of the term metabolism.”

So Schwann appears to have made several important contributions to science, but his most important one, for my purposes, is that his discovery of the organic nature of yeast influenced Pasteur.

Schwann was the first of Johannes Peter Müller’s pupils to break with vitalism and work towards a physico-chemical explanation of life. Schwann also examined the question of spontaneous generation, which led to its eventual disconfirmation. In the early 1840s, Schwann went beyond others who had noted simply the multiplication of yeast during alcoholic fermentation, as Schwann assigned the yeast the role of primary causal factor, and then went further and claimed it was alive. Embattled controversy ensued as eminent chemists alleged that Schwann was undoing scientific progress by reverting to vitalism.

After publishing anonymous mockery in a journal of their own editorship, they published a purely physicochemical if also hypothetical explanation of the interaction resulting in fermentation. As both the rival perspectives were hypothetical, and there was not even an empirical definition of ‘life’ to hold as a reference frame, the controversy—as well as interest itself—fell into obscurity unresolved. Pasteur began fermentation researches in 1857 by approximately just repeating and confirming Schwann’s, yet Pasteur accepted that yeast were alive, thus dissolving the controversy over their living status, and then Pasteur took fermentation researches further.

In retrospect, the germ theory of Pasteur, as well as its antiseptic applications by Lister, can be traced to Schwann’s influence.

In his biography on Famous Scientists, under the section entitled “Microbes, Yeast and Fermentation” it discusses his influence on Pasteur’s work on yeast in fermentation:

Schwann identified the role that microorganisms played in alcohol fermentation and putrefaction. He carried out a variety of fermentation experiments and by 1836 had gathered enough evidence to convince himself that the conversion of sugar to alcohol during fermentation was a biological process that required the action of a living substance (yeast) rather than a chemical process of sugar oxidation.

Unfortunately, Schwann’s explanation of fermentation was ridiculed by other scientists. Acceptance only came with Louis Pasteur’s work over a decade later. Pasteur later wrote in a letter to Schwann:

“For twenty years past I have been travelling along some of the paths opened up by you.”

LOUIS PASTEUR
Letter to Schwann, 1878

In a deeper dive about the history of yeast on Think Write Publish, entitled “For the Love of Yeast: A little cell at the cutting edge of big science,” by Molly Bain and Niki Vermeulen, in Chapter 2, they discuss Schwann, Pasteur and others unlocking the secrets of yeast’s role in fermentation:

People had been using yeast—spooning off its loamy, foamy scum from one bread bowl or wine vat and inserting it in another—for thousands of years before they understood what this seething substance was or what, exactly, it was doing. Hieroglyphs from ancient Egypt already suggested yeast as an essential sidekick for the baker and brewer, but they didn’t delineate its magic—that people had identified and isolated yeast to make bread rise and grape juice spirited was magic enough. As the great anatomist and evolutionary theory advocate Thomas Henry Huxley declared in an 1871 lecture, “It is highly creditable to the ingenuity of our ancestors that the peculiar property of fermented liquids, in virtue of which they ‘make glad the heart of man,’ seems to have been known in the remotest periods of which we have any record.”

All the different linguistic iterations of yeast—gäscht, gischt, gest, gist, yst, barm, beorm, bären, hefe—refer to the same descriptive action and event: to raise, to rise, to bear up with, as Huxley put it, “‘yeasty’ waves and ‘gusty’ breezes.” This predictable, if chaotic and muddy, pulpy process—fermentation—was also known to purify the original grain down to its liquid essence—its “spirit”—which, as Huxley described it, “possesses a very wonderful influence on the nervous system; so that in small doses it exhilarates, while in larger it stupefies.”

Though beer and wine were staples of everyday living for thousands and thousands of years, wine- and beer-making were tough trades—precisely because what the gift of yeast was, exactly, was not clear. Until about 150 years ago, mass spoilage of both commercial and homemade alcoholic consumables was incredibly common. Imagine your livelihood or daily gratification dependent on your own handcrafted concoctions. Now, imagine stumbling down to your cellar on a damp night to fetch a nip or a barrel for yourself, your neighbors, or the local tavern. Instead you’re assaulted by a putrid smell wafting from half of your wooden drums. You ladle into one of your casks and discover an intensely sour or sulfurous brew. In the meantime, some drink has sloshed onto your floor, and the broth’s so rancid, it’s slick with its own nasty turn. What caused this quick slippage into spoilage? This question enticed many an early scientist to the lab bench—in part because funding was at the ready.

In a 2003 article on yeast research in the journal Microbiology, James A. Barnett explains that because fermentation was so important to daily life and whole economies, scientific investigations of yeast began in the seventeenth century and were formalized in the eighteenth century, by chemists—not “natural historians” (as early biologists were called)—who were originally interested in the fermentation process as a series of chemical reactions.

In late eighteenth-century Florence, Giovanni Valentino Fabbroni was part of the first wave of yeast research. Fabbroni—a true Renaissance man who dabbled in politics and electro-chemistry, wrote tomes on farming practices, and helped Italy adapt the metric system—determined that in order for fermentation to begin, yeast must be present. But he also concluded his work by doing something remarkable: Fabbroni categorized yeast as a “vegeto-animal”—something akin to a living organism—responsible for the fermentation process.

Two years later, in 1789 and in France, Antoine Lavoisier focused on fermentation in winemaking, again regarding it as a chemical process. As Barnett explains, “he seem[ed] to be the first person to describe a chemical reaction by means of an equation, writing ‘grape must = carbonic acid + alcohol.’” Lavoisier, who was born into the aristocracy, became a lawyer while pursuing everything from botany to meteorology on the side. At twenty-six, he was elected to the Academy of Sciences, bought part of a law firm specializing in tax collection for the state, and, while working on his own theory of combustion, eventually came to be considered France’s “father of modern chemistry.” The French government, then the world’s top supplier of wine (today, it ranks second, after Italy), needed Lavoisier’s discoveries—and badly, too: France had to stem the literal and figurative spoiling of its top-grossing industry. But as the revolution took hold, Lavoisier’s fame and wealth implicated him as a soldier of the regime. Arrested for his role as a tax collector, Lavoisier was tried and convicted as a traitor and decapitated in 1794. The Italian mathematician and astronomer Joseph-Louis Lagrange publicly mourned: “It took them only an instant to cut off his head, and one hundred years might not suffice to reproduce its like.”

Indeed, Lagrange was onto something: the new government’s leaders were very quickly in want of scientific help for the wine and spirits industries. In 1803, the Institut de France offered up a medal of pure gold for any scientist who could specify the key agent in the fermenting process. Another thirty years passed before the scientific community had much of a clue—and its discovery tore the community apart.

By the 1830s, with the help of new microscope magnification, Friedrich Kützing and Theodor Schwann, both Germans, and Charles Cagniard-Latour, a Frenchman, independently concluded that yeast was responsible for fermenting grains. And much more than that: these yeasts, the scientists nervously hemmed, um, they seemed to be alive.

Cagniard-Latour focused on the shapes of both beer and wine yeasts, describing their cellular bulbous contours as less like chemical substances and more resembling organisms in the vegetable kingdom. Schwann pushed the categorization even further: upon persistent and continued microscopic investigations, he declared that yeast looks like, acts like, and clearly is a member of the fungi family—“without doubt a plant.” He also argued that a yeast’s cell was essentially its body—meaning that each yeast cell was a complete organism, somewhat independent of the other yeast organisms. Kützing, a pharmacist’s assistant with limited formal training, published extensive illustrations of yeast and speculated that different types of yeast fermented differently; his speculation was confirmed three decades later. From their individual lab perches, each of the three scientists concluded the same thing: yeast is not only alive, but it also eats the sugars of grains or grapes, and this digestion, which creates acid and alcohol in the process, is, in effect, fermentation.

This abrupt reframing of fermentation as a feat of biology caused a stir. Some chemist giants in the field, like Justus von Liebig, found it flat out ridiculous. A preeminent chemistry teacher and theorist, von Liebig proclaimed that if yeast was alive, the growth and integrity of all science was at grave risk: “When we examine strictly the arguments by which this vitalist theory of fermentation is supported and defended, we feel ourselves carried back to the infancy of science.” Von Liebig went so far as to co-publish anonymously (with another famous and similarly offended chemist, Friedrich Wöhler) a satirical journal paper in which yeasts were depicted as little animals feasting on sugar and pissing and shitting carbonic acid and alcohol.

Though he himself did little experimental research on yeast and fermentation, von Liebig insisted that the yeasts were just the result of a chemical process. Chemical reactions could perhaps produce yeast, he allowed, but the yeasts themselves could never be alive, nor active, nor the agents of change.
Von Liebig stuck to this story even after Louis Pasteur, another famous chemist, took up yeast study and eventually became the world’s first famous microbiologist because of it.

These long-term investigations into and disciplinary disputes about the nature of yeast reordered the scientific landscape: the borders between chemistry and biology shifted, giving way to a new field: microbiology—the study of the smallest forms of life.

Historic Beer Birthday: Antonie van Leeuwenhoek

October 24, 2020 By Jay Brooks Leave a Comment

Today is the birthday of Antonie van Leeuwenhoek (October 24, 1632–August 26, 1723). He “was a Dutch tradesman and scientist, and is commonly known as ‘the Father of Microbiology.'” Apropos of nothing, “his mother, Margaretha (Bel van den Berch), came from a well-to-do brewer’s family.” Despite hi family ties, van Leeuwenhoek didn’t discover anything specifically useful to the brewing industry, but he did find that there was life pretty much everywhere he looked, using his microscope, including the “microscope—tiny “animalcules,” including yeast cells, which he described for the first time” in 1674-80.” But he laid the groundwork for later scientists to figure how exactly yeast worked. As Brian Hunt wrote in the entry for “infection” in the “The Oxford Companion to Beer,” that “the existence of yeast as a microbe was only discovered in 1674 by Antonie van Leeuwenhoek, the inventor of the modern microscope.” Or as Sylvie Van Zandycke, PhD, put it. “The yeast Saccharomyces cerevisiae was used for thousands of years in the fermentation of alcoholic beverages before anyone realized it! The Dutch scientist, Anton Van Leeuwenhoek observed the mighty cells for the first time under the microscope in 1680.”

Here’s a short biography, from the Science Museum Brought to Life:

Leeuwenhoek was born in Delft in the Netherlands, to a family of brewers. He is known for his highly accurate observations using microscopes.

Leeuwenhoek worked as a draper, or fabric merchant. In his work he used magnifying glasses to look at the quality of fabric. After reading natural scientist Robert Hooke’s highly popular study of the microscopic world, called Micrographia (1665), he decided to use magnifying lenses to examine the natural world. Leeuwenhoek began to make lenses and made observations with the microscopes he produced. In total he made over 500 such microscopes, some of which allowed him to see objects magnified up to 200 times.

These were not the first microscopes, but Leeuwenhoek became famous for his ability to observe and reproduce what was seen under the microscope. He hired an illustrator who reproduced the things Leeuwenhoek saw.

In 1673 he began corresponding with the Royal Society of London, which had just formed. Leeuwenhoek made some of the first observations of blood cells, many microscopic animals, and living bacteria, which he described as ‘many very little living animalcules’. In 1680 his work was recognised with membership of the Royal Society – although he never attended a meeting, remaining all his life in Delft.

Leeuwenhoek with His Microscope, by Ernest Board (1877–1934)

Here’s a story from Gizmodo, by Esther Inglis-Arkell, explaining Antonie van Leeuwenhoek’s role and iviting readers to Meet The First Man To Put Beer Under A Microscope:

The man in the picture [the same one at the top of this post] is considered the “Father of Microbiology.” He helped to discover and sketch microorganisms. When he turned his microscope on beer, he saw some of the most useful microorganisms in the world — but he failed to recognize them.

This man above is Anton van Leeuwenhoek, and he’s wearing an absolutely bitchin’ coat because he was a draper by trade. In fact, he draped so successfully that he managed to indulge his hobbies as he got older, one of which was lens making. Anton spent his days making powerful microscopes and sketching the objects he put in front of them. He discovered many things, the most interesting of which were animalcules, things that looked like tiny little animals. His sketches and descriptions, as well as his microscopes, jumpstarted the field of microbiology.

It wasn’t long before he turned his lens on beer in the process of brewing. It was 1680 when he first trained his lens on a droplet of beer. At the time, no one knew what it was that made hops, barley, and water turn into beer. Although they knew of yeast as a cloudy substance that appeared in beer after it spent some time fermenting, they were entirely ignorant of what it did; to the point where there were laws against using anything except barley, hops, and water in the beer-making process. Naturally, as soon as Anton looked at brewing beer he saw little circular blobs. He saw the way they aggregated into larger groups. He saw the way that they produced bubbles of what he thought was “air,” and floated to the surface.

Despite his obsession with microorganisms, he utterly failed to recognize them as life. These blobs, he believed, had come loose from flour. They aggregated into groups of six as part of a chemical process. Anton was fascinated by these groups of flour globs. He modeled them in wax, because he wanted to figure out the ways six globs could stick together while all being visible from above. This is his sketch of his models.

It took another 150 years before Charles Canard-Latour figured out that the “air” was carbon dioxide and the sextets of blobs hadn’t aggregated together, they’d grown. Archaeologists believe that beer was probably first brewed around 3000 BC. That means that we used an organism for nearly 5,000 years before we realized it even existed.

Although van Leeuwenhoek did write about the wood used in beer barrels:

Historic Beer Birthday: John Gorrie

October 3, 2020 By Jay Brooks Leave a Comment

Today is the birthday of John Gorrie (October 3, 1803-June 29, 1855). He “was a physician, scientist, inventor, and humanitarian,” and most importantly, is credited with creating one of the very first refrigerators, an important development for the brewing industry.

Here’s one brief account, from a history of refrigeration on The Sun:

The man credited with developing the first actual “fridge” was an American doctor, John Gorrie, who built an ice-maker in 1844 based on Evans’ work of decades earlier. He also pioneered air conditioning at the same time, since his idea was to blow air across the ice-making machine to cool hospital patients suffering from malaria in Florida.

Gorrie did not make the fortune he deserved. His business partner died and his leaky machines were mocked by the Press and the ice-producing firms to whom he could have been a threat. He died sick and broke aged 51.

Here’s his story from his Wikipedia page:

Since it was necessary to transport ice by boat from the northern lakes, Gorrie experimented with making artificial ice.

After 1845, he gave up his medical practice to pursue refrigeration products. On May 6, 1851, Gorrie was granted Patent No. 8080 for a machine to make ice. The original model of this machine and the scientific articles he wrote are at the Smithsonian Institution. In 1835, patents for “Apparatus and means for producing ice and in cooling fluids” had been granted in England and Scotland to American-born inventor Jacob Perkins, who became known as “the father of the refrigerator.” Impoverished, Gorrie sought to raise money to manufacture his machine, but the venture failed when his partner died. Humiliated by criticism, financially ruined, and his health broken, Gorrie died in seclusion on June 29, 1855. He is buried in Magnolia Cemetery.

Another version of Gorrie’s “cooling system” was used when President James A. Garfield was dying in 1881. Naval engineers built a box filled with cloths that had been soaked in melted ice water. Then by allowing hot air to blow on the cloths it decreased the room temperature by 20 degrees Fahrenheit. The problem with this method was essentially the same problem Gorrie had. It required an enormous amount of ice to keep the room cooled continuously. Yet it was an important event in the history of air conditioning. It proved that Dr. Gorrie had the right idea, but was unable to capitalize on it. The first practical refrigeration system in 1854, patented in 1855, was built by James Harrison in Geelong, Australia.

Schematic of Gorrie’s ice machine.

And this account, entitled “Dr. John Gorrie, Refrigeration Pioneer,” is by George L. Chapel of the Apalachicola Area Historical Society in Apalachicola, Florida, which is the location of the John Gorrie State Museum:

Dr. John Gorrie (1803 – 1855), an early pioneer in the invention of the artificial manufacture of ice, refrigeration, and air conditioning, was granted the first U.S. Patent for mechanical refrigeration in 1851. Dr. Gorrie’s basic principle is the one most often used in refrigeration today; namely, cooling caused by the rapid expansion of gases. Using two double acting force pumps he first condensed and then rarified air. His apparatus, initially designed to treat yellow fever patients, reduced the temperature of compressed air by interjecting a small amount of water into it. The compressed air was submerged in coils surrounded by a circulating bath of cooling water. He then allowed the interjected water to condense out in a holding tank, and released or rarified, the compressed air into a tank of lower pressure containing brine; This lowered the temperature of the brine to 26 degrees F. or below, and immersing drip-fed, brick-sized, oil coated metal containers of non-saline water, or rain water, into the brine, manufactured ice bricks. The cold air was released in an open system into the atmosphere.

The first known artificial refrigeration was scientifically demonstrated by William Cullen in a laboratory performance at the University of Glasgow in 1748, when he let ethyl ether boil into a vacuum. In 1805, Oliver Evans in the United States designed but never attempted to build, a refrigeration machine that used vapor instead of liquid. Using Evans’ refrigeration concept, Jacob Perkins of the U.S. and England, developed an experimental volatile liquid, closed-cycle compressor in 1834.

Commercial refrigeration is believed to have been initiated by an American businessman, Alexander C. Twinning using sulphuric ether in 1856. Shortly afterward, an Australian, James Harrison, examined the refrigerators used by Gorrie and Twinning, and introduced vapor (ether) compression refrigeration to the brewing and meat packing industries.

The granting of a U.S. Patent in 1860 to Ferdinand P.E. Carre of France, for his development of a closed, ammonia-absorption system, laid the foundation for widespread modern refrigeration. Unlike vapor-compression machines which used air, Carre used rapidly expanding ammonia which liquifies at a much lower temperature than water, and is thus able to absorb more heat. Carre’s refrigeration became, and still is, the most widely used method of cooling. The development of a number of synthetic refrigerants in the 1920’s, removed the need to be concerned about the toxic danger and odor of ammonia leaks.

The remaining problem for the development of modern air conditioning would not be that of lowering temperature by mechanical means, but that of controlling humidity. Although David Reid brought air into contact with a cold water spray in his modification of the heating and ventilating system of the British Parliament in 1836, and Charles Smyth experimented with air cycle cooling (1846 – 56), the problem was resolved by Willis Haviland Carrier’s U.S. Patent in 1906, in which he passed hot soggy air through a fine spray of water, condensing moisture on the droplets, leaving drier air behind. These inventions have had global implications.

Dr. Gorrie was honored by Florida, when his statue was placed in Statuary Hall in the U.S. Capitol. In 1899, a monument to Dr. Gorrie was erected by the Southern Ice Exchange in the small coastal town of Apalachicola, where he had served as mayor in 1837, and had developed his machine.

Reportedly born October 3, 1803 in Charleston, South Carolina, of Scots – Irish descent, he was raised in Columbia, S.C. He attended the College of Physicians and Surgeons of the Western District of New York, in Fairfield, New York, from 1825 to 1827. Although the school lasted only a few decades, it had a profound influence, second only to the Philadelphia Medical School, upon the scientific and medical community of the United States in the 19th century. Young Asa Gray, from Oneida County, New York, who by 1848 would be ranked as the leading botanist in the United States, and who in time would become a close friend of Dr. Alvin Wentworth Chapman of Apalachicola, the leading botanist in the South, served as an assistant in the school’s chemical department. In later years, Dr. Gray had distinct recollections of Gorrie as a “promising student.”

Dr. Gorrie initially practiced in Abbeville, South Carolina, in 1828, coming to the burgeoning cotton port of Apalachicola in 1833. He supplemented his income by becoming Assistant (1834), then Postmaster in Apalachicola. He became a Notary Public in 1835. The Apalachicola Land Company obtained clear title to the area by a U.S. Supreme Court decision in 1835, and in 1836 laid out the city’s grid-iron plat along the lines of Philadelphia, Pennsylvania. Gorrie, who served as Vice-Intendant in 1836, and Intendant (Mayor), in 1837, would be an effective advocate for the rest of his life for draining the swamps, clearing the weeds and maintaining clean food markets in the city. He first served as Secretary of the Masonic Lodge in 1835, was a partner in the Mansion House Hotel (1836), President of the Apalachicola Branch Bank of Pensacola (1836), a charter member of the Marine Insurance Bank of Apalachicola (1837), a physician for the Marine Hospital Service of the U.S. Treasury Department (1837 – 1844), and a charter incorporator and founding vestryman of Trinity Episcopal Church, Apalachicola (1837).

Dr. Gorrie married Caroline Frances Myrick Beman, of a Columbia, South Carolina family, the widowed proprietress of the Florida Hotel in Apalachicola, on May 8, 1838. Shortly thereafter, he resigned his various positions in Apalachicola, and the family left the city not to return until 1840. He was named Justice of the Peace in 1841, the same year that yellow fever struck the area.

Mal-aria, Italian, “bad air”, and yellow fever, prevailed in the hot, low-lying, tropical and sub-tropical areas where there was high humidity and rapid decomposition of vegetation. Noxious effluvium, or poisonous marsh gas was thought to be the cause. The “putrid” winds from marshy lowlands were regarded as deadly, especially at night. The specific causes were unknown, and although one had quinine for malaria, the gin and tonic of India, there was no cure nor preventive vaccine, for yellow fever. The legendary Flying Dutchman was founded on the story of a ship with yellow fever onboard.

Malaria would start with shaking and violent chills, followed by high fever, and a drenching sweat. Insidious, it could recur in the victim as well as kill. Yellow fever did not recur; one either died or survived. It came in mysterious, vicious waves, killing anywhere from 12 to 70 percent of its victims. It started with shivering, high fever, insatiable thirst, savage headaches, and severe back and leg pains. In a day or so, the restless patient would become jaundiced and turn yellow. In the terminal stages, the patient would spit up mouthfuls of dark blood, the terrifying “black vomit” (vomito negro), the body temperature would drop, the pulse fade, and the comatose patient, cold to the touch, would die in about 8 to 10 hours. So great was the terror, that the victims would be buried as quickly as possible. Areas would be quarantined, and yellow flags flown. Gauze would be hung over beds to filter air; handkerchiefs would be soaked in vinegar; garlic would be worn in shoes. Bed linens and compresses would be soaked in camphor; sulfur would be burned in outdoor smudge pots. Gunpowder would be burned, and cannons would be fired. And, later, when it was over, the cleaning and fumigating would occur.

It would not be until 1901 in Havana, Cuba, that Drs. Walter Reed, Carlos Finlay and William Crawford Gorgas, with others, would demonstrate conclusively that the Aedes Aegypti, or Stegomyia Fasciata mosquito was the carrier of the yellow fever virus. It would be about the same time that the English physician, Sir Ronald Ross in India, would correctly identify the Anopheles mosquito as the carrier of the malaria protozoa. As early as 1848, in Mobile, Alabama, however, Dr. Josiah Nott first suggested that mosquitos might be involved. The yellow fever epidemic of 1841, and the hurricane and tidal wave, known locally as the “Great Tide” of 1842, destroyed Apalachicola’s rival cotton port of St. Joseph some thirty miles to the west on the deep water sound of St. Joseph’s Bay. Using Florida’s first railway (1837) to transport cotton from the Apalachicola River, St. Joseph had hosted Florida’s Constitutional Convention in 1838.

Dr. Gorrie became convinced that cold was the healer. He noted that “Nature would terminate the fevers by changing the seasons.” Ice, cut in the winter in northern lakes, stored in underground ice houses, and shipped, packed in sawdust, around the Florida Keys by sailing vessel, in mid-summer could be purchased dockside on the Gulf Coast. In 1844, he began to write a series of articles in Apalachicola’s “Commercial Advertiser” newspaper, entitled, “On the prevention of Malarial Diseases”.

He used the Nom De Plume, “Jenner”, a tribute to Edward Jenner, (1749 – 1823), the discoverer of smallpox vaccine. According to these articles, he had constructed an imperfect refrigeration machine by May, 1844, carrying out a proposal he had advanced in 1842. All of Gorrie’s personal records were accidentally destroyed sometime around 1860.

“If the air were highly compressed, it would heat up by the energy of compression. If this compressed air were run through metal pipes cooled with water, and if this air cooled to the water temperature was expanded down to atmospheric pressure again, very low temperatures could be obtained, even low enough to freeze water in pans in a refrigerator box.” The compressor could be powered by horse, water, wind driven sails, or steampower.
Dr. Gorrie submitted his patent petition on February 27, 1848, three years after Florida became a state. In April of 1848, he was having one of his ice machines built in Cincinnati, Ohio, at the Cincinnati Iron Works, and in Octobcr, he demonstrated its operation. It was described in the Scientific American in September of 1849. On August 22, 1850, he received London Patent #13,124, and on May 6, 1851, U. S. Patent #8080. Although the mechanism produced ice in quantities, leakage and irregular performance sometimes impaired its operation. Gorrie went to New Orleans in search of venture capital to market the device, but either problems in product demand and operation, or the opposition of the ice lobby, discouraged backers. He never realized any return from his invention. Upon his death on June 29, 1855, he was survived by his wife Caroline (1805 – 1864), his son John Myrick (1838 – 1866), and his daughter, Sarah (1844 – 1908). Dr. Gorrie is buried in Gorrie Square in Apalachicola, his wife and son are buried-St. Luke’s-Episcopal Cemetery, Marianna, Florida, and his daughter, in Milton, Florida.

Historic Beer Birthday: John Ewald Siebel

September 17, 2020 By Jay Brooks 2 Comments

Today is the birthday of John Ewald Siebel (September 17, 1868-December 20, 1919). Siebel was born in Germany, but relocated to Chicago, Illinois as a young man. Trained as a chemist, in 1868 he founded the Zymotechnic Institute, which was later renamed the Siebel Institute of Technology.

Here’s his obituary from the Foreign Language Press Survey:

Professor John Ewald Siebel has died after an active life devoted to science. Besides his relatives, thousands of his admirers, including many men of science, mourn at the bier of the friendly old man. He died in his home at 960 Montana Avenue.

Professor Siebel was born September 18, 1845, in Hofkamp, administrative district of Dusseldorf [Germany], as the son of Peter and Lisette Siebel; he attended high school [Real-Gymnasium] at Hagen and studied chemistry at the Berlin University. He came to the United States in 1865 and shortly afterwards obtained employment as a chemist with the Belcher Sugar Refining Company in Chicago. Already in 1868, he established a laboratory of his own, and from 1869 until 1873 he was employed as official chemist for the city and county. In 1871 he also taught chemistry and physics at the German High School. From 1873 until 1880 he was official gas inspector and city chemist. During the following six years he edited the American Chemical Review, and from 1890 until 1900 he published the Original Communications of Zymotechnic Institute. He was also in charge of the Zymotechnic Institute, which he had founded in 1901. Until two years ago he belonged to its board of directors.

Among the many scientific works published by the deceased, which frequently won international reputation, and are highly valued by the entire world of chemical science are: Newton’s Axiom Developed; Preparation of Dialized Iron; New Methods of Manufacture of Soda; New Methods of Manufacture of Phosphates; Compendium of Mechanical Refrigeration; Thermo-and Electro-Dynamics of Energy Conversion; etc. The distilling industry considered him an expert of foremost achievement.

The deceased was a member of the Lincoln Club; the old Germania Club; the local Academy of Science; the Brauer and Braumeisterverein [Brewer and Brewmaster Association]; the American Institute for Brewing; and the American Society of Brewing Technology. Professor Siebel was also well known in German circles outside the city and state.

His wife Regina, whom he married in 1870….died before him. Five sons mourn his death: Gustav, Friedrich, Ewald, Emil and Dr. John Ewald Siebel, Jr. Funeral services will be held tomorrow afternoon at Graceland Cemetery.

Professor Siebel was truly a martyr of science. He overworked himself, until a year ago he suffered a nervous breakdown. About four months ago conditions became worse. His was an easy and gentle death.

The Siebel Institute’s webpage tells their early history:

Dr. John Ewald Siebel founded the Zymotechnic Institute in 1868. He was born on September 17, 1845, near Wermelskirchen in the district of Dusseldorf, Germany. He studied physics and chemistry and earned his doctorate at the University of Berlin before moving to Chicago 1866. In 1868 he opened John E. Siebel’s Chemical Laboratory which soon developed into a research station and school for the brewing sciences.

In 1872, as the company moved into new facilities on Belden Avenue on the north side of Chicago, the name was changed to the Siebel Institute of Technology. During the next two decades, Dr. Siebel conducted extensive brewing research and wrote most of his over 200 books and scientific articles. He was also the editor of a number of technical publications including the scientific section of The Western Brewer, 100 Years of Brewing and Ice and Refrigeration.

In 1882 he started a scientific school for brewers with another progressive brewer but the partnership was short lived. Dr. Siebel did, however, continue brewing instruction at his laboratory. The business expanded in the 1890’s when two of Dr. Siebel’s sons joined the company.

The company was incorporated in 1901 and conducted brewing courses in both English and German. By 1907 there were five regular courses: a six-month Brewers’ Course, a two-month Post Graduate Course, a three-month Engineers’ Course, a two-month Maltsters’ Course and a two-month Bottlers’ Course. In 1910, the school’s name, Siebel Institute of Technology, was formally adopted. With the approach of prohibition, the Institute diversified and added courses in baking, refrigeration, engineering, milling, carbonated beverages and other related topics. On December 20, 1919, just twenty-seven days before prohibition became effective, Dr. J. E. Siebel passed away.

With the repeal of prohibition in 1933 the focus of the Institute returned to brewing under the leadership of F. P. Siebel Sr., the eldest son of Dr. J. E. Siebel. His sons, Fred and Ray, soon joined the business and worked to expand its scope. The Diploma Course in Brewing Technology was offered and all other non-brewing courses were soon eliminated. Then in October 1952, the Institute moved to its brand new, custom built facilities on Peterson Avenue where we have remained for almost 50 years.

Siebel Brewers Academy c. 1902-04.

Here’s another short account from the journal Brewery History, in an article entitled “A History of Brewing Science in the United States of America,” by Charles W. Bamforth:

Dr John Ewald Siebel (1845-1919) was born on September 17th 1845 at Hofcamp, near Düsseldorf. Upon visiting an uncle in US after the completion of his doctorate in chemistry and physics he became chief chemist at Belcher’s sugar refinery in Chicago, aged 21, but that company soon folded. Siebel stayed in Chicago to start an analytical laboratory in 1868, which metamorphosed into the Zymotechnic Institute.

With Chicago brewer Michael Brand, Siebel started in 1882 the first Scientific School for practical brewers as a division of the Zymotechnic Institute. True life was not breathed into the initiative until 1901 with Siebel’s son (one of five) Fred P. Siebel as manager. This evolved to become the Siebel Institute of Technology, which was incorporated in 1901 and conducted brewing courses in both English and German. Within 6 years five regular courses had been developed: a six-month course for brewers, a twomonth post graduate course, a threemonth course for engineers, a two-month malting course and a two-month bottling course.

Amongst Siebel’s principal contributions were work on a counter pressure racker and artificial refrigeration systems. Altogether he published more than 200 articles on brewing, notably in the Western Brewer and original Communications of the Zymotechnic Institute. Brewing wasn’t his sole focus, for instance he did significant work on blood chemistry.

Son EA Siebel founded Siebel and Co and the Bureau of Bio-technology in 1917, the year that prohibition arrived. Emil Siebel focused then on a ‘temperance beer’ that he had been working on for nine years. Courses in baking, refrigeration, engineering, milling and nonalcoholic carbonated beverages were offered.

And here’s the entry for the Siebel Institute from the Oxford Companion to Beer, written by Randy Mosher:
